1 www.rheintechnik.com Pregnancy diagnosis Simple. Accurate. Reliable.
2 Modern ultrasound diagnostics for daily farming Reliable pregnancy diagnosis forms the basis for successful reproductive management in livestock farming. With its modern range of Rheintechnik-branded ultrasound devices, Kerbl offers solutions to meet a variety of requirements: for piglet producers and sheep breeders, the cost-effective all-rounder PRO and the modern wireless WRLS with a sector probe; for cattle and horse owners and veterinarians, the advanced EXPERT with a 6.5 MHz rectal probe. Whether a compact entry-level solution or a high-performance professional unit – all products have been developed for daily use in the barn and convince with their easy to use nature, robust construction and good image quality. How it works The basic principle is based on the fact that animal organs have different densities. The ultrasound probe generates an ultrasound wave. This is reflected differently by various types of tissue or liquids. The probe converts the echo waves into electrical signals, which are displayed as images on screens. Tips: • Sows should not be fully fed prior to examination • The probe must be applied with sufficient pressure • Using a viscous, bubble-free scanning gel makes the work easier and ensures sufficient contrast in the image • As the pregnancy progresses, the ovarian structures move towards the front and the probe must be repositioned accordingly Function Product images Model PRO WRLS EXPERT # 221301 221300 221302 Weight 750 g 410 g 1229 g Dimensions 250 x 130 x 50 mm 231 x 52 x 79 mm 213 x 225 x 60 mm Probe 3.5 MHz mechanical sectoral 3.5 MHz mechanical-sectoral 6.5 MHz linear-rectal Scan depth 60–190 mm 79–197 mm 80–240 mm Modes B, B+B, B+M, M B B, B+B, 4B, B+M, M Screen size 5.6” 8.4" 8" battery 3350 mAh (>4h) 5,200 mAh (4.5 hours) 6,800 mAh (>7 hours) Product benefits Affordable & proven technology Wireless flexibility For large animals and professionals (veterinarians) Types of animal (symbols) Pigs, sheep, goats, alpacas Pigs, sheep, goats, alpacas Cattle, horses (rectal) Pigs, sheep (convex) RSP
3 Ultrasound Scanner PRO incl. probe Compact, portable scanner with a 3.5 MHz sector probe for reliable pregnancy control on pigs, sheep, goats and alpacas, supplied as a complete set in a robust case. A cost-effective tool for every farmer. • Handheld scanner with low weight and a bottle holder for the ultrasound gel – making it easy to work even under unfavourable conditions • Can detect pregnancy in pigs from the 21st day and in sheep from the 30th day onwards • Scan depth of up to 190 mm • 5.6” TFT screen with 256 grey scales and a high resolution of 960 x 640 pixels • Good image quality thanks to practical image adjustment options: adjustment frequency, gain, brightness and contrast • Images can be displayed in different colours and up to 128 images can be saved • The user can choose between different screen modes (B, B+B, B+M, M) and can thus compare their display with saved images • Features a freeze function for detailed viewing or exporting images • Circumference and area measurements, as well as distance measurements for up to four distances simultaneously – enabling to predict the EDC (Expected Date of Confinement) based on foetal heart size • High-performance lithium-ion battery (3,350 mAh) for long operating times of 4 hours or more • protective cover with neck strap included in set Technical data Weight 750 g Dimensions 25 x 13 x 5 cm Greyscale 256 Frequency 3.5 MHz Scan depth 60–190 mm Image mode B, M, BB, BM Zoom 1.0, 1.2, 1.5, 2.0 Memory 128 images Battery capacity 3,350 mAh (Li-ion) Max. operating time > 4 hours Screen 5.6” TFT-LCD Resolution 960 x 640 pixels Ref. No. RSP 221301 Ref. No. Description RSP 221301-4 Neck strap for PRO ultrasound device 221301-5 Bottle holder for PRO ultrasound device 221301-8 UK plug A cost-effective device suitable for any piglet farmer bottle holder Splash-proof cover length-adjustable neck strap long battery runtime included in delivery: 1x main unit, 1x 3.5 MHz mechanical probe, 1x protective cover with neck strap, 1x bottle holder for ultrasound gel, 1x power pack with charging cable, 1x carrying case 480 min
4 Wireless Ultrasound Scanner WRLS Ergonomic, compact, battery-operated 3.5 MHz ultrasound probe for reliable pregnancy monitoring in pigs, sheep, goats and alpacas, designed for professional users. The scanner stands out for its easy handling and high image quality. Calculation of backfat and loin muscle thickness, and estimation of gestational age. • The probe transmits the live image wirelessly to a mobile device (tablet or smartphone). No internet connection is required. A connection is established solely between the transducer and the display device. • Pregnancy can be detected in pigs from the 21st day and in sheep from the 30th day onwards • Simply stable and smooth operation thanks to a 2.4 GHz connection to the display device (Wi-Fi: 802.11g, Android • Unlike conventional scanners, the curved shape of the scanner ensures fatigue-free work that is gentle on the back and wrists • Choice of 7 scan depths (79 mm – 197 mm) and 2 frequencies (2.5 MHz and 3.5 MHz) • Advanced image processing technology and 256-level greyscale display • Precise image adjustments possible: gain, near-field, far-field, dynamic range • Images can be frozen (Freeze) and later compared with new scans, or exported as BMP, JPG, PNG or even as a video (MP4) • Automatic capture of animal numbers via scanning is possible. Results can be assigned directly to the relevant animal within the app. • Measurement function: distance, ellipse and punctuation methods for measuring distance, circumference, area and volume. This allows loin depth and backfat, as well as GSD (Gestation Start Date) and EDC (Expected Date of Confinement). • Hygienic cleaning of the transducer with water or 75% alcohol is possible (IP X4) • A high-capacity Li-ion battery (5200 mAh) provides up to 4.5 hours of running time and can then be quickly recharged using the supplied USB-C cable or the optionally available car charger. • Handy wrist strap, leaving one hand free to hold the ultrasound gel • Delivery in a case as a set, with the app pre-installed on the tablet included in delivery: 1x 3.5 MHz sectoral scanner, 1x 8.4” tablet, 1x protective cover for tablet, 1x neck strap for tablet, 1x smartphone holder with wrist strap, 1x USB-C cable, 1x carrying case • modern, cordless ultrasound scanner • The scanner’s curved shape ensures fatigue-free work that is gentle on the back and wrists • available as a complete set, or as a single scanner to use with your own mobile phone or tablet (Android) Software Download The required software can be downloaded from the App Store/Google Play or from the website https://go.kerbl.com/9kZbwp. waterproof probe RFID scanning of ear tags including a tablet wrist strap App Download
5 Technical data Probe weight 410 g Probe dimensions 231 x 52 x 79 mm Greyscale 256 Frequency 3.5 MHz Scan depth 79–197 mm Sector angle 80° operating system Android Battery capacity 5200 mAh (Li-ion) Max. operating time 4.5 hours Wi-Fi 802.11g / 20 MHz / 2.4 GHz (local) Image format bmp, jpg, png, mp4 Charging 100–240 V Protection type IPX 4 Image mode B Technical data LCD screen Screen 8.4” HD Model Alldocube Mini 2 Processor 2.2 GHz (Snapdragon 6 series) Storage 128 GB Operating system Android Dimensions 202 x 126 x 7.5 mm Resolution 1920 x 1280 pixels, 2.0–2.2K Battery 5500 mAh flexible and usable User interface Scanned image Ref. No. Description RSP 221300 Complete set: WRLS scanner, tablet and accessories in a case 221305 WRLS ultrasound scanner only 221306 8.4” tablet with cover, arm strap and neck strap 221307 Cover 8.4" tablet 221308 Neck strap for 8.4" tablet 221309 Smartphone holder with wrist strap 221310 Car charger 3 A, 100 W 221305 221306 221307 221308 221309 221310
6 Ultrasound Scanner EXPERT incl. rectal probe The EXPERT portable ultrasound scanner is a handy and powerful device which, thanks to its included 6.5 MHz rectal probe, is especially suitable for pregnancy detection examinations in cattle and horses. Ideally suited for professional use by large animal vets, breeders and cooperatives. • Large 8-inch high-resolution colour LCD screen (1024x720 pixels), with 96 crystals and excellent contrast, enabling a reliable diagnosis even under difficult conditions • Scan depth on the main unit is flexibly adjustable from 80 to 240 mm • offers a wide range of settings, including gain, image smoothing, brightness, contrast, frequency, focus, gamma correction, dynamic range adjustment and Cine-Loop • with measurement functions for length, circumference, area and volume, as well as specialised measurements for pregnancy diagnosis • practical quick saving buttons, a grid button for rapid size estimation, and a freeze button • Start-up time: <10 seconds • the user can choose between different screen modes (B, B+B, 4B, B+M, M) and can thus compare his display with saved images or detect the heart rate • 8 GB image storage and a USB-A connection for saving, playing back and analysing examination images on external media • over 7 hours of continuous operation thanks to a powerful 6800 mAh lithium battery. Should this prove insufficient, the battery can be removed without tools and charged externally, whilst you can continue working with the optionally available replacement battery • is waterproof according to IPX6 standard, means it can be cleaned under running water • weighs just 1229 g despite its large screen and powerful battery • In its standard configuration, the device is fitted with a 6.5 MHz rectal linear probe (64 mm long, 0.8 mm pitch, scan depth 80–120 mm), which is specifically designed for rectal examinations of cows, horses, sheep or pigs • is ideal for pregnancy testing in cattle and horses, as well as for controlling ovaries • A 3.5 MHz convex probe is also available as an optional extra for the device (60 mm, scan depth 120–240 mm, wide beam angle), which can be used to carry out external examinations on large and small animals • Supplied in a sturdy carrying case. Neck strap, battery and charger included; dark cover and extension handle available as optional extras • Instructions for use in the local language and local service included in delivery: 1x main unit, 1x 6.5 MHz rectal probe, 1x charger power pack with charging cable, 1x neck strap, 1x carrying case Technical data Weight 1229 g Dimensions 213 x 225 x 60 mm Greyscale 256 Frequency 6.5 MHz Scan depth 80–240 mm Zoom 1.0, 1.2, 1.5, 2.04 Image mode B, M, B+B, 4B, B+M Storage 8 GB Battery voltage 11.1 V Battery capacity 6,800 mAh Max. operating time >7 h Screen 8” LCD Resolution 1024 x 720 Can be combined with various probes; suitable for use with different types of animal User interface
7 Ultrasound gel Rheintechnik’s scanner gel is a clear contact medium that ensures optimum contact between the transducer and the animal’s skin. • viscous, non-drip ultrasound gel with excellent wetting properties, • water-soluble, easy to remove • completely bubble-free and manufactured under vacuum, thereby ensuring excellent sound transmission properties • pH-neutral, making it gentle on the skin and kind to equipment • free from formaldehyde, colourants and fragrances • non-sterile • for use in agriculture and veterinary medicine Ref. No. Description RSP 221302-1 3.5 MHz convex probe 221302-2 6.5 MHz linear rectal probe 221302-4 Extension handle for rectal probe for pigs and sheep 221302-6 Dark cover with neckstrap 221301-8 UK plug Ref. No. Contents RSP 221313 250 ml Application bottle 221314 5 l Refill canister 221315 Ø35 mm dispensing pump 221302-1 221302-4 221301-8 221313 221314 221315 221302-6 221302-2 Made in Germany
8 Kerbl UK Ltd 8 Lands End Way Oakham, Rutland LE15 6RF UK Phone +44 1572 722558 enquiries@kerbl.co.uk www.rheintechnik.com HK Rheintechnik, a brand of Albert Kerbl GmbH Felizenzell 9 84428 Buchbach Germany Tel.: +49 8086 933-100 info@kerbl.com www.rheintechnik.com PR497-26=Rheintechnik_Ultraschallsortiment_EN_102026 © 10/2026 HK and Rheintechnik are registered trademarks of Albert Kerbl GmbH. We do our best to constantly improve our range of products and keep it up-to-date. Thus we reserve the right to change the design of our products. With the publication of this catalogue all previous catalogues and price lists for the respective products are void. All prices provided are the manufacturer‘s recommended retail prices and are inclusive of VAT. All information is subject to typing and printing errors. All prices are subject to change. Changes in colour and design may occur due to printing technology reasons. Reprinting in whole or in part is due to prior authorisation.
