Water bowl technology for stable and pasture

Water bowl technology for stable and pasture www.kerbl.de

2 Choosing the right water bowls should be a priority in professional cattle and horse husbandry. A sufficient water supply is essential for the health of the animals. It is especially important for the animals’ well-being on hot summer’s days. Lactating cows, for example, need up to 150 litres of water and more in high heat. Animals have to be able to drink sufficient water, without barriers or stress, in order to safeguard their performance and well-being. Kerbl has been producing its own tried and tested water bowls for years. Convenience and comfort for both animals and people is our top priority. Working together with working farms and extensive field testing during the development phase allow us to tailor our products to the precise needs of the users. Explanation of our packaging and sales units. Items/pack unit No. of items per order unit/ pack unit OU Order unit for retail Always order a multiple of the number stated (e.g. OU = 12 items, order in lots of 12). Price/€ Price per OU If the OU column is empty or missing, the price is per item. All prices provided are the manufacturer‘s recommended retail prices and are inclusive of VAT. Pack units Possible pack units for 1 OU. Pallet No. of order units (OU) per pallet. Forwarder All items marked with this icon must be shipped by freight carrier due to their scale/size or weight. This means that additional, separate freight costs are required! Optimise freight costs by ordering entire pallet units. MOQ Pieces / unit € 1 blister pack Pack of 6 Price per pack 1 pouch Pouch of 10 Price per pouch 12 items Pouch of 12 Price per item 1 pack Pack of 30 Price per pack 40 items Pack of 40 Price per item 1 box Box of 5 Price per box 8 items Box of 8 Price per item 1 display Display of 10 Price per display 6 items Display of 6 Price per item

3 Good to know about drinkers Water is the most important and cheapest feedstuff. Sufficient supply is essential for the animals’ welfare and health. The following aspects should be observed here: • Water quality • Availability • Temperature • Ingredients Water consumption and installation data for common animals The values and heights mentioned are approximate. Each situation will require adaptation to species and purpose. Water intake is also highly dependent on ambient temperature. Necessary water flow Use drinking bowls with a suitable water flow per minute so that the animals take in sufficient water. Examples: Dairy cow: Cows take in 5-8 L/min on average. Right after milking, a cow can drink up to 20 L/min. Horse: Water intake varies between 3.5 and 7 L/min. If the water flow cannot be increased, select a water bowl with a larger volume. This will still provide sufficient water to the animal. Cow drinking behaviour Consequences of water shortages in dairy cows • Lower milk production • Reduction of rumen activity • Less intake of dry matter • Lower urinary excretion • Higher concentration of urine contents • Increased burden on the circulatory system Type of animal Water consumption Mounting heights Number of animals/drinking station Dairy cow up to 150 L/day (stabling) – 55 - 125 L/day (grazing) 70–100 cm 10 Mother cow 35 - 75 L/day (grazing) 70–100 cm 10 Young cattle 60 - 90 L/day 60–70 cm 15 Calf 17 - 20 L/day 40–60 cm 10 Horses 20 - 60 L/day 110–120 cm 15 Pony 20 - 60 L/day 55–90 cm 15 Sheep 5 - 8 L/day Step + 50 cm 25 Share of daily water consumption per cow Time of day Milking Feeding Milking 0:00 0 % 2 % 4 % 6 % 8 % 10 % 12 % 2:00 4:00 6:00 8:00 10:00 12:00 14:00 16:00 18:00 20:00 22:00

4 1 4 3 2 3 2 Good to know about drinkers Horse drinking behaviour Ration Anteil der täglichen Menge Time of day Ration Ration Tips for water bowls in barns • There should be a 60 cm clearance above the water bowl. This means animals can drink easily and quickly and that sloshing is minimised. • Animals should have a constant water supply available in order to have a positive influence on the productivity and growth of the animals. • Do not install the drinking station next to the feeding station. This would risk soaking the feed or dirtying the water bowl with food residues. • The placement of the water bowls should be oriented around the animals’ behaviour and be placed on the work walkways in order to facilitate water bowl cleaning and inspection. • At least two water stations should be installed separately for herd management. Animals can only drink undisturbed in this way. Furthermore, water bowls should not be set up in corners or dead ends; instead, place them in open areas to avoid contact between higher-ranking and low-ranking animals and to enable evasion. Placement of water bowls in barns Feed Alley Work Alley Calf Pen Mother cow barn Calving Pen 0:00 0 % 2 % 4 % 6 % 8 % 10 % 12 % 2:00 4:00 6:00 8:00 10:00 12:00 14:00 16:00 18:00 20:00 22:00 1. 2. 3. 4.

5 1 3 3 3 2 2 6 1 5 4 3 2 3 3 2 Boxes Waiting Bay (optional) Milking Robot Single Bay Good to know about drinkers Horse stable Work Alley Specifics for cattle • The distance between the water bowls should be max. 15 m, otherwise water intake will decrease. • In narrow walkways, space-saving individual/double water troughs should be used for preference. • Water bowls with a high flow rate and high bowl volume should be installed directly after the milking area in order to quench the high water requirements of dairy cows. Water troughs are recommended here. • For calves, water bowls with a constant water level should be used and they should be adapted to their body height. Specifics for horses A metal guard can be mounted around the water bowl if a horse hits its head or stamps a lot, in order to protect both animal and water bowl from damage. In foal rearing boxed, a distance of max. 5 cm between guard and water bowl should be maintained so that foals don’t get their legs caught. Feed Alley Milking stand Pen with milking robot Pen with milking stand 1. 2. 3. 4. 5. 6.

6 Good to know about drinkers Placement of water bowls in pastures • Animals should have a constant water supply available in order to have a positive influence on the productivity and growth of the animals. • At least two water stations should be installed separately. Animals can only drink undisturbed in this way. Furthermore, water bowls should not be set up in corners, dead ends or narrow walkways; instead, place them in open areas to avoid contact between higher-ranking and low-ranking animals and to enable evasion. • Water bowls do not necessarily have to be in shaded areas. Animals will seek out cooler shade in hot temperatures. If there is a water bowl there, the animals will jostle for the water bowls and dominant animals will claim the water bowl for themselves. It is recommended to install the water bowl near a shaded rest area. • In general, the water bowls should be somewhat larger to ensure a good supply and to prevent long waiting times and jostling. • It is recommended to fix pasture water bowls to the ground so that animals cannot move them. • Pasture water bowls should be cleaned and emptied before winter. Specifics for cattle • The distance between the water bowls should be max. 200 m, otherwise water intake will decrease. • For calves, water bowls with a constant water level should be used and they should be adapted to their body height. • Findings from dairy farm practice (milking robots with grazing) show that exclusive watering in barns has no effect on the frequency of milking. However, if a water bowl is placed on the pasture, the animals spend more time grazing. No water connection available Pasture Pump The pasture pump is suitable for water bowl water intake from open waters, reservoirs and tanks and pumps water from a depth of up to max. 7 - 8 metres. However, please note the rules and regulations. The suction line may not be under pressure, e.g. from a higher intake point than the pump itself. Water tank / water container Water bowls can also be connected to water tanks or water containers. You can select either float water bowls or paddle water bowls. How it works The animal pushes the lever forward with its head. The tie rod lifts the membrane and draws water into the membrane chamber. Gravity and the tension in the membrane push the lever backwards again. The water is forced out of the membrane chamber and flows into the drinking trough. The non-return valves ensure that the water is always drawn up and pumped in the right direction. Some of the pumped water remains on the upper side of the membrane and flows into the drinking trough as soon as the membrane is reactivated during the next cycle, i.e. when the animal presses the lever again (double-stroke function). Bearing points with slide bearings Aluminium lever Drinking trough made of cast iron Non-return valves Tie rod Rubber membrane Thread and hose connection made of brass

7 Explanation of terms Bar Bar is a common unit for water pressure. The pressure in a water pipe is usually expressed in bar and indicates the force with which the water is pressed against a surface (e.g. valve surface). The water pressure can be measured using a pressure gauge. High pressure Various valves designed for high pressure or low pressure in the water line can be installed in water bowls. If the water is coming from a domestic connection or a pump system, you need a water bowl or valve designed for high pressure. KERBL water bowls have a high pressure range of between 1– 5 bar. For pressures over 5 bar we recommend installing a pressure reducer ahead of the water bowl. Low pressure If water is drawn from a pasture barrel or other raised container without a pump or additional pressure booster, a low pressure water bowl or a low pressure valve is required. KERBL water bowls have a low pressure range of between 0.3 - 1 bar. Water flow rate The water flow rate, the volume flow or flow rate is the amount of water that flows through the cross-section of the water pipe or water bowl valve per minute and is expressed in litres per minute (e.g. 8 L/min). Volt Volts are the measurement of electric voltage, expressed in V (Volts). A normal domestic installation socket has a voltage of 230 V. The voltage can be reduced to e.g. 24 V by means of a protective isolating transformers for use with water bowls. Voltages up to 48 V are not dangerous for the human body and animals. Watts Watts are the unit for electric power, expressed in W (watts). A water bowl can be operated at 230 V or 24 V. As the same heating temperature is required to keep both drinking bowls frost-free, the same electric power is required despite the different voltages (24 V = 30 watts; 230 V = 30 watts). Partition systems according to EN 1717 It should be noted that water contaminated by animals falls under category 5 according to EN 1717. If a water bowl is connected to a water line that is connected to the public water supply system and does not itself separate the water surface from the supply system via a free outflow as per EN 1717, then the water bowl installation must be separated from the public and domestic water supply using a system separator with a free outflow as per EN 1717-type AA. The right water bowl type What you should consider when selecting the right water bowl: 1. High pressure or low pressure? • High pressure – is the water bowl going to be connected to the domestic supply? • Low pressure – is the water bowl going to be supplied using a water container without a pressure booster? 2. Species and group or individual housing? • Which animals are you providing water to and how old are they? (see next water bowl valve type evaluation below) • How large is the group? • What are the water needs of each animal? • Min. water flow of the valve? • Size of the tank volume? 3. Does the water bowl have to be frost-proof, i.e. heatable? • Will the heating system for the lines be laid in the browsing area? - 24 V • Is the lines’ heating system going to be laid outside the browsing area or can it be protected from browsing? - 230 V Good to know about drinkers IBC containers – the practical alternative to pasture barrels Another option for ensuring water supply without a water connection is to use an IBC container. We offer yet another fast and easy solution for mounting a feeding bucket using our mounting plate and connector set for IBC containers.

8 Good to know about drinkers Evaluation of the water bowl valve types The various water bowl types are evaluated below with a description of their suitability for certain species. Open trough drinkers with float valve: Open water stations reflect natural drinking in nature. The animal can submerse their mouths and take in large quantities of water in a short time. Trough drinkers are suitable for all animal species, especially for lactating cattle who should take in a lot of water in a short time. Water bowl valve used: A float valve is mostly used here. The float, a floating hollow body, attached to a lever arm which opens or closes the valve nozzle through its lever action. If the set water level is not reached, the valve nozzle is opened and closed again once the water level has reached its ‘target’ again. This means there is always water in the water bowl. Float water bowl: Float water bowls are characterised by open water surfaces with a constant water level. They are especially suitable for young animals (e.g. calves), sheep, goats and animals with sensitive snouts or weaning aids. Water bowl valve used: A float valve is used here, just like in the trough drinker. The float valves used in float water bowls are mostly smaller and have a lower flow rate than in trough drinkers. Otherwise the function is the same. Pipe valve water bowl: Pipe valves are primarily suitable for animals that cannot press hard with the bridge of the nose and for skittish animals. Suitable for all animal species, especially for horses as well as individual watering stations. Potentially not suitable for beef cattle. Water bowl valve used: The pipe valve or nozzle can easily be actuated by the bridge of the animal’s nose without great effort. The water than runs through the ‘pipe’ at the lower end into the floor waterer. Paddle valve water bowl: This kind of water bowl is primarily suited for powerful animals (e.g. cattle) due to the larger force required to actuate the valve using the ‘paddle’. Water bowl valve used: The ‘paddle’ (pressure valve) actuates the valve behind it upon being pressed from the front. When the animal presses on the ‘paddle’, the valve behind it opens and water runs into the floor waterer. 221140 221851 225031 222070

9 Good to know about drinkers Material and surface coating of the drinking bowl Grey Cast Iron Cast iron material with a high carbon fibre content. Mainly used in paddle valve water bowls. Surface: Powder-coated With powder-coated bowls, an electrically conductive body (grey cast iron) is coated with powder coating and then fused to the body. the material is characterised by: • high impact strength and mechanical strength • good weather resistance • optimal cleaning possible • good corrosion resistance • eco-friendly (solvent-free) workmanship Surface: enamelled High-quality, branded ceramic compound on steel castings. the material is characterised by: • good mechanical resistance • high resistance to surface wear • good weather resistance • optimal cleaning possible • high corrosion resistance • eco-friendly (solvent-free) workmanship Plastic The material is characterised by: • higher impact strength and elasticity than steel castings • good insulating thermal properties • no surface coating required Stainless steel The material is characterised by: • very high corrosion resistance • very easy to clean • no surface coating required • very long life 221140 222020 221500 221875

10 Frost Protection Drinkers Heated 24 V water bowls – how do they work? 24 V systems are primarily used for stables where the electrical wires could be damaged by browsing and where a 230 V system could present a risk to the animals and also to people under certain circumstances. An isolating transformer (e.g. item no 222798) is required to operate one or more 24 V water bowls. The transformer reduces the mains voltage of 230 V AC to max. 24 V AC. The selected transformer should ensure that the power of the transformer is greater than the accumulated power of the connected equipment. Example: 2 x heating cables (3 metres, 30 watts; item no. 223581) + 2 x water bowls H10 (50 watts; item no. 222005) = 160 watts -> 200 watt transformer (item no. 222797) is required The transformer should never be fully utilised by the connected equipment, and the total power should certainly never exceed its limits, as otherwise the required heat output of the heating cables and water bowl heaters cannot be provided. Please also note that selecting a too small cable cross section for the lead from the transformer to the water bowl can result in the loss of a lot of power. Optimal cable length and cross section is important for keeping the water pipes and water bowls safely free from frost. Please refer to the table with the maximum supply line lengths and cross sections for the output to be transmitted. Therefore, place the transformer as close as possible to the equipment (heating cables, water bowl heaters). It must be installed away from the browsing area, protected from water and be mounted away from the spray area of the water bowl. Heated 230 V water bowls – how do they work? If the electric leads are reliably protected from browsing, then 230 V systems can also be used. The advantage of 230 V systems is in the reliable transmission of the required heating power over long distances and relatively small cable cross-sections. When using metal pipelines, the grounding clamps absolutely must be separately earthed and secured. This is for protection if browsing does occur and/or the heating cable insulation or the water bowl supply cable is damaged and this is due to the pipeline. Please note that 130 V electrical installations must be carried out by an electrician.

11 Frost Protection Drinkers HP20, item No. 222050 230 Volt / 73 Watt, with auxiliary pipe heating HP20, item No. 222040 230 Volt / 31 Watt H10, item No. 222005 24 Volt / 50 Watt HP20, item No. 222045 24 Volt / 31 Watt HP20, item No. 222055 24 Volt / 73 Watt, without auxiliary pipe heating Water line Supply line 230 Volt (three-wire) Heating cable 230 Volt Supply line 24 Volt (two-wire) Heating cable 24 Volt heated supply line Installation diagram shown without insulation and bite protection! Heating cable, 3 m 24 Volt, 30 W Item No. 223581 Earth connection on the metal pipe, when using pipe-laying heating cables > 48 V Socket, 230 V each separately fused with: - B10 A or B16 A circuit breaker - Residual current circuit breaker 30 mA Heating cable, 3 m 24 Volt, 30 W Item No. 223581 Junction box Junction box Junction box Optional: Frost protection thermostat, item No. 222794 Switching the entire heating installation on and off. Must be positioned in the coldest spot in the stall. Heating cable, 12 m 230 Volt, 192 W Item No. 223588 Minimum distance 0.5 m from the thermostat of one 230 V heating cable to the next heating cable Safety transformer 200 Watt, item No. 222797 Calculation: (1 x 50 W + 1 x 31 W+ 2 x 30 W) x 1.15 = 163 W Safety transformer 300 Watt, item No. 222626 Calculation: (3 x 73 W + 1 x 30 W) x 1.15 = 287 W 230 Volt installations must be configured by a qualified specialist. Filter unit and shutoff device Supply line coming from a secure separation according to DIN EN 1717 - Type AA, Type AB 230 V 1 24 V 1 1 1 1 1

12 Water Bowl Heatable H10 • drinking bowl made of gray cast iron, black enamelled • Grey cast iron bottom tray, black power-coated finish • water flow rate can be regulated on the pipe valve • new heating concept with valve heating to keep clear of frost • easy to install bowl, no need to remove the valve for installation • power supply via transformer at least 100 W (not supplied) • suitable for circulating heating systems • simple electrical connection through the terminal box on the outside • for wall and pipe mounting frost-protected down to approx. -20 °C ​ ​ 24 V pin can be connected to the 24 V conduit without disassembling the drinking bowl 222019 Ø 1-3“ Technical data ​ Dimensions (W x D x H) 25,8 x 28,2 x 17,8 cm Connection option from above or below Flow rate 8 L/min at 3 bar Weight 11,5 kg Ref. no. Colour Heating output Voltage Water connection Capacity ​ ​ € 222010 black 80 W 24 V G 1/2“ 1,6 L 1 48 ​ 222005 black 50 W 24 V G 1/2“ 1,6 L 1 48 ​ Ref. no. Description ​ Length Width Height ​ € 222019 Pipe Mounting Brackets, in pairs ​ ​ ​ ​ 1 ​ 221971 Guard Size 2 ​ ​ ​ ​ 1/4 ​ 221975 Protection against chewing for pipelines ​ 100 cm 13,2 cm 8 cm 1 ​ Frost Protection Drinkers Upper shell Heating element Lower shell 80 W or 50 W

13 Frost Protection Drinkers Water Bowl Heatable HP20 • drinking bowl made from high-quality plastic (PP) with integrated heating cable • heating cable easy to replace • integrated frost protection thermostat (switch-on temperature approx. +3 °C, switch-off temperature approx. +13 °C) • controllable water flow rate (up to 11 litres/minute) • suitable for circulating heating systems • with outlet plug for easy cleaning • for wall and pipe mounting frost-protected down to approx. -25 °C ​ ​ 222019 Ø 1-3“ with integrated pipe heating 4 variants with auxiliary pipe heating, 73 W without auxiliary pipe heating, 31 W 24 V 222055 222045 230 V 222050 222040 Technical data ​ Connection option from above or below Flow rate 10 L/min at 3 bar Weight 2 kg Ref. no. Colour Pipe Heating Heating output Voltage Water connection Capacity ​ ​ € 222040 green without pipe heating 31 W 230 V G 1/2“ 2,8 L 1 60 ​ 222050 green with auxiliary pipe heating 73 W 230 V G 1/2“ 2,8 L 1 60 ​ 222045 green without pipe heating 31 W 24 V G 1/2“ 2,8 L 1 60 ​ 222055 green with auxiliary pipe heating 73 W 24 V G 1/2“ 2,8 L 1 60 ​ Ref. no. Description ​ Length Width Height ​ € 222019 Pipe Mounting Brackets, in pairs ​ ​ ​ ​ 1 ​ 221971 Guard Size 2 ​ ​ ​ ​ 1/4 ​ 221975 Protection against chewing for pipelines ​ 100 cm 13,2 cm 8 cm 1 ​ Drain plug External frost-protection thermostat The cover on the underside of the bowl and the closed construction in the area of the valve inlet have an insulating effect and prevent heat emitted by the heating cable from escaping. Heating cable • 222040 and 222045: Heating cable (approx. 31 W) for heating the drinking bowl and valve • 222050 and 222055: Heating cable (approx. 73 W) for heating the drinking bowl, valve and up to 2 metres of pipeline (auxiliary pipe heating) • a transformer is required for the 24 V version (not included)

14 Float Water Bowl Heatable SH30 • drinking bowl made from high-quality plastic with integrated heating cable • integrated frost protection thermostat (switch-on temperature approx. +3 °C, switch-off temperature approx. +13 °C) • heating cable easy to replace • suitable for circulating heating systems • valve cover with snap hook for rapid access • with valve type 22182 also suitable for connection to low pressure • with outlet plug for easy cleaning • for wall and pipe mounting frost-protected down to approx. -15 °C ​ ​ with integrated pipe heating 4 variants with auxiliary pipe heating, 73 W without auxiliary pipe heating, 31 W 24 V 222065 222063 230 V 222064 222062 Technical data ​ Connection option from left or right Flow rate 6 L/min at 3 bar Weight 2,7 kg Ref. no. Colour Pipe Heating Heating output Voltage Water connection Capacity ​ ​ € 222062 green without pipe heating 31 W 230 V G 1/2“ 5 L 1 42 ​ 222063 green without pipe heating 31 W 24 V G 1/2“ 5 L 1 42 ​ 222064 green with auxiliary pipe heating 73 W 230 V G 1/2“ 5 L 1 42 ​ 222065 green with auxiliary pipe heating 73 W 24 V G 1/2“ 5 L 1 42 ​ Ref. no. Description ​ ​ € 222019 Pipe Mounting Brackets, in pairs ​ 1 ​ 22192 Floating valve High pressure ​ 1/50 ​ 22182 Floating valve Low pressure ​ 1/100 ​ Drain plug External frost-protection thermostat The cover on the underside of the bowl prevents the heat given off by the heating cable from escaping. • 222062 + 222063: with heating cable (approx. 31 W) for heating the drinking bowl and valve • 222064 + 222065: with heating cable (approx. 73 W) for heating the drinking bowl, valve and up to 2 metres of pipeline (auxiliary pipe heating). • a transformer is required for the 24 V version (not included) Frost Protection Drinkers

15 Frost-Protection Accessories Which transformer should be used? If you want to operate a water bowl with 80 watts of power (supplied), then a 100-watt transformer will suffice (item no. 222796). If you also want to connect a 24 V heating cable, simply add the current consumption (= wattage) of the cable. When selecting the transformer, plan for a power reserve of 15 % (factor 1.15). Please ensure you select the correct cable cross-section. If the cable cross-section selected is too small, it cannot transmit the full power and the water bowl system can freeze under certain circumstances despite heating. Selection of the required transformers: Calculation example for transformer: 1 x 300 watts (VA) transformer (item no. 222626) for: 2 x water bowl HP20 216 watts x 1.15 = 249 watts 246 watts < 300 watts 1 x 200 watts (VA) transformer (item no. 222797) for: 2 x water bowl H10 + 2 x heating cable 160 watts x 1.15 = 184 watts 184 watts < 200 watts Number Water Bowls / Heating Cables ​ ​ 3 Water Bowl HP20 24 Volt (item no. 222055) 3 x 73 watts = 216 watts 2 Water Bowl H10 24 Volt (item no. 222005) 2 x 50 watts = 100 watts 2 Frost Protection Heating Cable - 24 Volt (item no. 223581) 2 x 30 watts = 60 watts ​ ​ Total power: = 376 watts ​ Calculate the total power required with power reserve: ​ ​ ​ ​ 376 watts x 1.15 (+ 15 %) = 433 watts + Transformer for trough heating • transforms the voltage from 230 volts to 24 volts • can be used for all frost-free waterers • Short circuit and overload protection through easily replaceable automotive fuse in the output circuit • the transformers are also secured against overheating thanks to an integrated temperature limiter (automatic reset after cool-down) • IP 65 (transformer) / IP 20 (connection) • Produced using vacuum casting: the best possible protection against moisture, mechanical and electronic loads ​ ​ ​ Conventional car microfuses for safe operation of the installation Ref. no. Thickness ​ € 222796 100 VA 1 ​ 222797 200 VA 1 ​ 222626 300 VA 1 ​ 222798 400 VA 1 ​ Made in Germany

16 The following table is a quick overview of cable lengths and cross-sections: Maximum cable length in metres for the following cable cross-sections and transmittable powers: Which cable should I use? If the 24 V supply has to cover a larger distance between the transformer and the heater or the heated water bowl, please pay attention to the cable cross-section, to prevent the risk of drops in voltages along the cable’s route. Calculation to ascertain the minimum cable cross-section: Power x cable length / 3200 W/m = cable cross-section (ACable) In the example above, a distance of 25 metres between the transformer and the heater and/or water bowl and a transmittable power of 292 watts would produce the following: (292 W x 25 m: 3200 W/m) mm² = 2.3 mm² In this case, use a cable with a cross-section of at least 2.3 mm² should be used. Therefore, you should select a cable with a cross section of 2.5 mm². ​ ​ ​ ​ ​ 1.5 mm² ​ 24 m 16 m 12 m 2.5 mm² 80 m 40 m 27 m 20 m 4.0 mm² 128 m 64 m 43 m 32 m 6.0 mm² 192 m 96 m 64 m 48 m Frost-Protection Accessories Frost protection heating pipe 24 V • for heating the spur line of waterers • a 24 V transformer is required for operation • IPX7 ​ ​ ​ Ref. no. Heating output Length ​ ​ € 22358 15 W 1,5 m 1/50 720 ​ 223581 30 W 3 m 1/40 720 ​

17 Frost-Protection Accessories Frost Protection Thermostat • suitable for all bowl and tube heating systems • External probe ensures automatic switching on and off • in the splash-proof housing • max. permitted power 3.6 kW • IP54 The frost protection thermostat should be installed at the coldest point. ​ ​ Ref. no. ​ € 222794 1/30 ​ Advantages: • the frost-protection installation is not turned on when there is no risk of frost • the thermostat automatically switches the frost-protection elements on or off • the operating temperature can be freely adjusted Protection against chewing for pipelines • reliable protection for pipes fitted with heating cables and insulation • Material thickness: 1 mm ​ ​ ​ Ref. no. ​ Length Width Height ​ € 221975 ​ 100 cm 13,2 cm 8 cm 1 ​ Aluminium Adhesive Tape • for heat reflection on water pipes • around 25 m aluminium adhesive tape is required for a 3.5 m long 3/4“ pipe Tip: You always need aluminium adhesive tape for plastic pipes, otherwise there will be no heat conduction ​ ​ Wrap the plastic water lines from the heating cable assembly with aluminium adhesive tape Ref. no. Length Width ​ € 222809 100 m 50 mm 1/54 ​

18 Frost-protection heating lines • prevent water pipes from freezing • thermostat in the heating cable switches the cable on automatically What to remember about 230 V heating cables: • installation must be carried out by a qualified professional in accordance with VDE0100 • always attach the heating cable to the underside of the pipe • the water pipe must be earthed • 230 V heating cables are ready to connect and should be connected to a power supply with a 30 mA residual current circuit breaker • the heating cables must not be shortened • the heating cable must not be 600 mm shorter or longer than the pipe section to be heated • excess length can be wound around the end of the pipe (note that a winding distance of at least 50 mm must be maintained between coils) • do not bend heating cables and note the maximum bending radius of approx. 20 mm What should you consider when using plastic water pipes? Never install heating cables directly on plastic pipes. The plastic pipe must be completely pasted with an aluminium adhesive tape (item no. 222809) beforehand for better heat transfer. It is important that only plastic pipes that are suitable for hot water installations are used. Otherwise, damage to the pipeline and water leakage can occur. Pipe Ø 15 mm Ø 22 mm ½“ Ø 28 mm ¾“ Ø 35 mm 1“ Ø 42 mm 1 ¼“ Ø 48 mm 1 ½“ Ø 60 mm 2“ Ø 76 mm 2 ½“ with insulation (max. 13 mm) frost-resistant to - 45 °C - 45 °C - 40 °C - 40 °C - 35 °C - 30 °C - 25 °C - 20 °C Frost Protection Heating • heating cables can be secured to the pipe with insulating tape or aluminium tape (222809) • the heating cable must only be used on plastic resistant water lines approved for hot water that are always filled with water • if using plastic pipes, wrap aluminium tape (222809) around the pipe before routing the heating cable • if using plastic pipes, please pay attention to the separate, specific assembly instructions • insulate the pipeline and heating cable with non-flammable insulation of max. 13 mm • attach the heating cable thermostat to the coldest part of the pipe • do not use 230 V heating cables in the bite area of animals Should pipelines and heating cables be insulated? The pipeline and heating cable should be insulated with a heat-resistant insulation made from mineral wool or foam of max. 13 mm thickness in order to ensure efficient operation of the installation.

19 Frost Protection Heating Frost protection heating pipe with thermostat • keeps your water line frost-free to -45 ° C • integrated frost protection thermostat (switch-on temperature approx. +3 °C, switch-off temperature approx. +13 °C) • not suitable for heating pipes • do not insulate the thermostat when adding insulation • Protect the area animals could chew on with a bite protector • Connector cable length: 2 m • Mechanical strength class M1 (not suitable for gutters or other applications with mechanical load) • VDE-approved heating pipe (except 49 m heating pipe) • 230 V • IPX7 frost-protected down to max. -45 °C Do not mount in animal feed area unprotected - use only 24-volt heating cable. Do not shorten the heating cable! ​ Ref. no. Heating output Length Plug type MOQ Pieces / unit ​ ​ € 223582 16 W 1 m with earthed plug 1 blister pack 1 / blister pack 1/16 192 ​ 223585 32 W 2 m with earthed plug 1 blister pack 1 / blister pack 1/16 192 ​ 223586 64 W 4 m with earthed plug 1 blister pack 1 / blister pack 1/16 192 ​ 223587 128 W 8 m with earthed plug 1 blister pack 1 / blister pack 1/16 192 ​ 223588 192 W 12 m with earthed plug 1 blister pack 1 / blister pack 1/16 192 ​ 223590 224 W 14 m with earthed plug 1 blister pack 1 / blister pack 1/16 192 ​ 223589 288 W 18 m with earthed plug 1 blister pack 1 / blister pack 1/12 100 ​ 223591 384 W 24 m with earthed plug 1 blister pack 1 / blister pack 1/12 100 ​ 223592 592 W 37 m with earthed plug 1 blister pack 1 / blister pack 1/5 75 ​ 223593 784 W 49 m with earthed plug 1 blister pack 1 / blister pack 1/5 60 ​ Pipe Insulation max. 13 mm Insulating cover Heating cable

20 Gutter heating cable Frost Protection Heating Cable for Gutters and Pipes The plug-in heating cable, suitable for gutters and pipes, meets the requirements of strength class M2 as per IEC60800:2009 to keep gutters and pipes safely above freezing. The high heating power of 20 watts per metre means the heating cable keeps gutters, downspouts and piping frost-free even at very low temperatures. The integrated temperature switch reliably switches the heating cable on at a temperature of +3 °C and off again at +12 °C. • suitable for gutters: Strength class M2 • ready-to-plug heating cable for easy installation • integrated thermostat for energy-saving use • suitable for metal water pipes • incl. safety plug for high level of safety • Connector cable length: 2 m • High protection: IPX7 • Protection class: I ​ ​ with earthed plug integrated thermostat for energy-saving use 296097 296097 Ref. no. Heating output Length Ø ​ ​ € 296087 100 W 5 m 6 mm 1/10 100 ​ 296088 200 W 10 m 6 mm 1/10 100 ​ 296089 300 W 15 m 6 mm 1/10 100 ​ 296090 400 W 20 m 6 mm 1/10 100 ​ 296091 500 W 25 m 6 mm 1/10 80 ​ 296092 800 W 40 m 6 mm 1/10 80 ​ 296093 1.000 W 50 m 6 mm 1/10 80 ​ Ref. no. Description MOQ Pieces / unit ​ € 296097 Spacer for Heating Cable incl. cable tie 1 pack 5 / pack 1/250 ​ 296098 Kink protection for heating cables incl. cable tie ​ ​ 1/100 ​ 296099 Personal safety switch ​ ​ 1 ​ New product Frost Protection Heating 296098 Note: • Please note that each heating cable connection must be fused via a separate residual current circuit breaker (E.g. item no. 296099, plug-in PRCD switch). • The heating cable must be protected against sharp edges, e.g. where the guttering meets the downpipe, using edge protection (item no. 296098). • The heating cable must not overlap, cross over or be in contact with itself or another heating cable at any point. To permanently prevent contact, we recommend the use of suitable spacers if necessary (item no. 296097). • For safety reasons, pipes and metal guttering, protective tubes and sheathing must be earthed before installation.

21 Circulation Pump C10 circulation pump with integrated heating element for year-round operation The ideal solution for supplying animals with water at a pleasant temperature. The constant movement of the water and the switchable heating provide double anti-freezing protection. • 3-step switch: 0 = Off, 1 = Circulation mode, 2 = Circulation and heating mode • automatic control of the set water temperature • automatic safety shut-off in case of overheating • the LED on the control box indicated whether the heater is turned on and heating • air vent valve on the radiator • circulation pump with three different speeds • easy installation by an authorised expert • low space requirement due to compact design • very easy to maintain • components can be quickly disconnected and disassembled • for drinking systems with a loop length of max. 250 m (and a pipe diameter of 3/4”) • Stainless steel housing • flow indicator and thermometer available as optional accessories • Water connection: 1“ (inlet and outlet) • Voltage: 230 V ​ ​ Included in delivery: 1 x circulation pump, 1 x flow tube with integrated heating element, 1 x non-return valve, 1 x air vent, 1 x overpressure valve, 1 x pump screw connector G 1 ½“ - Rp. 1” for circulation pump Ref. no. Length Width Height pump capacity Heating output ​ € 223130 52 cm 41,5 cm 26,5 cm 50 W 3.000 W 1 ​ Ref. no. Description ​ € 223131 Flow Indicator with Float - connection thread DN25 G1“ 1 ​ 223132 thermometer connection with thermometer - connection size DN25 1 ​ Made in Germany New product C10 circulation pump

22 C10 circulation pump Maximum achievable length of the ring line with 3/4“ tubes or tubes with at least 20 mm inner diameter T-pieces, branches, and spur lines must be avoided within the ring pipe. Unavoidable spur lines must be protected against frost using auxiliary pipe heating. 1 metre should be deducted from the total cable length for each elbow piece and T-piece in the ring pipe. Maximum achievable length of the ring line with 1/2“ tubes or tubes with at least 15 mm inner diameter A circulation pump keeps the water in a ring pipe in permanent circulation and thus in constant motion. The risk of microbial contamination is reduced, increasing water quality. Spur lines should be avoided in circulation systems, as bacteria can multiply rapidly, particularly in stagnant water. Good water quality is a basic prerequisite of animal health. As the failure of the circulation pump and heater would lead to the ring pipe and water bowl freezing relatively quickly, suitable alarm systems (e.g. acoustic signals) should be integrated into the installation so that you can react quickly in event of failure. The circulation pump itself must be installed in a frost-free room. Max. ring line length in metres Max. ring line length in metres max. number of water bowls per ring pipe (closed ring pipe per circulation pump) max. number of water bowls per ring pipe (closed ring pipe per circulation pump) The constant circulation of the water in the ring pipe minimises freezing at low temperatures, compared to standing water. In order to keep the ring pipe frostfree even at very low temperatures, the C10 circulation pump also has a 3 kW heating element that heats the water and can be switched on manually if required. The heating element automatically switches on if the temperature drops below the set thermostat temperature. Insulated pipelines are a basic prerequisite for proper functioning. The maximum practical length of the ring pipe is 250 metres, and depends heavily on the number of installed water bowls, branch lines and arches. insulated polyethylene pipeline length insulated galvanised steel pipeline length non-insulated polyethylene pipeline length non-insulated galvanised steel pipeline length insulated polyethylene pipeline length insulated galvanised steel pipeline length non-insulated polyethylene pipeline length non-insulated galvanised steel pipeline length 1 2 3 4 5 6 7 8 9 1011121314151617181920 0 50 100 150 200 250 123456789101112 0 20 40 60 80 100 120 140

23 C10 circulation pump Connection diagram The entire ring pipe must be adequately insulated in the frost-risk area. In the browsing area, any insulation and additional electrical cables must be protected against browsing. Frost-risk area Frost-proof area Installation with the BYPASS system – the ball cocks allow the pump to be separated quickly and easily from the ring pipe and to be emptied via the drain valve. With a 3/4 ” pipe diameter, up to 250 m of ring pipe are possible. Max. pumping height: 6 m. The following accessories for creating the pipework are included: 1 x overpressure safety valve 6 bar, 1 x quick exhaust valve 3/8 ”, 1 x non-return valve 1 ” The unit guttering and pipelines must be installed only by an authorised specialist. As per the Drinking Water Ordinance and EN 1717, the installation and use of a system disconnector must be tested. 1. C10 Circulation Pump (223130) 2. 3/8“ Quick Exhaust Valve 3. 1“ Check Valve for Water Inlet 4. 6-bar Overpressure Safety Valve 5. DN25 G 1“ Flow Indicator with Float 6. DN25 Thermometer Connection with 1¼ „ Cover 7. Shut-off Valve for Circulation Pump 8. Shut-off Valve for Bypass Pipe 9. Shut-off Valve for Supply Pipe 10. Drain Valve for Circulation Pump 11. Water filter (optional) 12. Drain Valve for Ring Pipe 13. Insulation 14. Browsing Protection 15. Junction box with residual current circuit breaker for circulation pump 30 mA

24 Frost Protection Drinkers With thermal water bowls, also called ball water bowls, the water bowls are kept frost-free in winter freezing temperatures even without electricity if enough animals frequent the water bowl. The water line must be routed to the water bowl in a frost-free area of the ground (approx. 0.8 metres under the surface. Constant water intake by the animals means that earth-warmed water (approx. +5 °C) can continue to flow into the water bowl and is kept at temperature and thus frost-free by the bowl walls, which are insulated with thermal foam, and the bowl lid. The balls, also filled with thermal foam, close the drinking openings in the lid after ever use by the animal, preventing the water cooling too quickly and thus freezing. When drinking, the animal pushes the ball inwards and to the side. The water bowl’s good thermal insulation means the water stays pleasantly cool even in the summer, ensuring a pleasant drinking temperature all year round. The ball closure at the drinking holes largely prevents contamination of the water. The thermal water bowls have at least one plug so that water and dirt can be quickly drained from the water bowl. In order to reduce any potential manure entering the drinking station, it is recommended to mount the heated water bowls on a concrete base of at least 20 cm height according to the installation instructions. Connection diagram 1. Pipe insulation 2. Ground insulating seal 3. braided stainless steel hose 4. double sealing strips 5. Float valve 6. Ball 7. PU hard foam insulation 8. large fast-acting drain 9. Concrete step plinth (at least 15 cm thick) 10. frost-resistant depth (0.8 – 2.0 m, depending on region) 11. Water inlet, 1/2” 12. Open to the ground, so that ground heat can rise 13. Pipe: Minimum diameter 30 cm

25 Thermal Trough • high insulation through double wall with a thermal foam filling • stays frost-free thanks to flowing water • constant water temperature (approx. 3 to 5 °C in winter, approx. 10 to 12 °C in summer), pleasant for animals all year round • fast emptying and rinsing thanks to large drain with ø 100 mm • enclosed housing prevents soiling and ensures optimum water hygiene • no mains supply needed • incl. base seals, spare gaskets for float valve and drain plug, flexible stainless steel hose, pipe insulation, floor anchor • for floor mounting • with drain plug 100 mm • Material: Plastic Duo: • 20 animals recommended minimum stocking • for feeding water to up to 30 animals Uno: • 10 animals recommended minimum stocking • for feeding water to up to 15 animals frost-protected down to approx. -30 °C ​ ​ 223600 Size of outlet openings Float valve with water flow up to 35 L/min 223610 Technical data 223600 223610 Dimensions (W x D x H) 108,5 x 70 x 52,5 cm 60 x 70 x 52,5 cm Connection option from below from below Flow rate 24 L/min at 3 bar 24 L/min at 3 bar Ref. no. Description Water connection Capacity ​ ​ € ​ 223600 Duo G 1/2“ 100 L 1 4 ​ ​ 223610 Uno G 1/2“ 40 L 1 8 ​ ​ Ref. no. Description ​ € 223601 Floating valve 1/10 ​ Frost Protection Drinkers

26 Browsing catalogue and service pages If you don‘t have one of our catalogues to hand, or simply want to browse through our collection with the ‘true’ catalogue feeling, then our online browsing catalogue is exactly what you need. The services pages on our website also contain generally useful forms such as repair requests, pick-up requests for dry batteries and return slips. Discover our range of online services. Just as we are constantly striving to improve our existing products and develop new ones, we are mindful too of our services that accompany our product portfolio. With our free newsletter and news on our website, we pick out exclusive products and topics of seasonal interest for you and provide you with information on very special offers. We also endeavour to make your product experience more extensive and informative with videos, brochures and other information. We’d like to give you a closer look at a few of our highlights here. Kerbl goes Social Media You too can find us on social media, on Facebook, Instagram and YouTube. This way, you won’t miss out on Kerbl’s latest news about our company, products and activities. You can find an overview of all social media channels at: https://www.kerbl.de/socialmedia Professional advice from Kerbl

27 Do you require specific advice on our products? Our specially trained product experts are available for your questions and can provide detailed information at any time via phone or e-mail for the following product areas. For more information about these product areas, please go to our website. www.kerbl.de Service department Telephone Email IP Camera ​ ​ Germany: +49 8086 933-545 support_ipcam@kerbl.com Austria: +43 4224 81555-645 kamera@kerbl-austria.at International: +49 8086 933-545 support_ipcam@kerbl.com LED Lighting ​ ​ Germany: +49 8086 933-551 led@kerbl.com Austria: +43 4224 81555-646 led@kerbl-austria.at International: +49 8086 933-551 led@kerbl.com Drinking Technology ​ ​ Germany: +49 8086 933-520 traenketechnik@kerbl.com Austria: +43 4224 81555-647 traenketechnik@kerbl-austria.at International: +49 8086 933-520 drinkingbowls@kerbl.com Clippers ​ ​ Germany: +49 8086 933-552 schermaschinen@kerbl.com Austria: +43 4224 81555-648 schermaschinen@kerbl-austria.at International: +49 8086 933-552 clippers@kerbl.com Pest Control ​ ​ Germany: +49 8086 933-554 schaedlingsbekaempfung@kerbl.com Austria: +43 4224 81555-649 schaedlingsbekaempfung@kerbl-austria.at International: +49 8086 933-554 pestcontrol@kerbl.com Fencing ​ ​ Germany: +49 8086 933-577 weidezaun@kerbl.com Austria: +43 4224 81555-651 weidezaun@kerbl-austria.at International: +49 8086 933-577 fencing@kerbl.com Hoof Care ​ ​ Germany: +49 8086 933-541 klauenpflege@kerbl.com Austria: +43 4224 81555-653 klauenpflege@kerbl-austria.at International: +49 8086 933-541 clawcare@kerbl.com Feed ​ ​ Germany: +49 8086 933-321 futter@kerbl.com Austria: +43 4224 81555-652 futter@kerbl-austria.at International: +49 8086 933-321 supplementfeed@kerbl.com Hobby Farming ​ ​ Germany: +49 8086 933-323 hobbyfarming@kerbl.com Austria: +43 4224 81555-655 hobbyfarming@kerbl-austria.at International: +49 8086 933-323 hobbyfarming@kerbl.com Smartfarming ​ ​ Germany: +49 8086 993-301 smartfarming@kerbl.com Austria: +43 4224 81555-654 smartfarming@kerbl-austria.at International: +49 8086 993-301 smartfarming@kerbl.com Professional advice from Kerbl
